From Gas to Electric: New Power Capabilities to Laser

December 1, 2010

More than 30 years of effort have been devoted to bringing the chemical oxygen iodine laser (COIL) into existence, with the goal of creating a high-energy device that could reliably knock out ballistic missiles during their initial boost phase.

The COIL’s operation at infrared wavelengths, and hence its ability to propagate long distances through the atmosphere without distortion, made it a prime candidate for the Airborne Laser (ABL) program — a Missile Defense Agency (MDA) project to put a giant laser on a modified Boeing 747. However, the high-powered laser has a number of drawbacks when it comes to applications that are less ambitious than those involved in ABL.

First, a typical COIL setup is enormous — in the range of tens of thousands of pounds — and also involves a “witch’s brew” of chemicals such as corrosive chlorine gas and concentrated basic hydrogen peroxide (BHP). CU Aerospace (Champaign, IL), while making great strides in MDA space-based infrared (SBIR) systems for the development of the COIL, has also investigated other means of creating a similar laser called the ElectricOIL.

How it Works

The ElectricOIL offers a significant size, weight, and safety advantage over the COIL. Instead of massive tanks needed to house BHP and chlorine gas, the ElectricOIL uses a simple electrical discharge sustained in a mixture of oxygen and helium, with a small amount of iodine added downstream to help generate the excited lasing atoms.

Aside from its high-powered profile designed for advanced air maneuvers, when operating at optimum powers, COIL and ElectricOIL lasers would be far superior to yttrium-aluminum-garnet and carbon-dioxide lasers in cutting speed and robotically controlled precision for fiber optic-delivery. If one wanted to adapt its abilities to terrestrial applications, however, the ElectricOIL would be the laser of choice.

One ElectricOIL device could replace ten standard cutting lasers by routing laser energy through ten different fiber-optic pathways. Such a capability would be valuable in areas of industry where rapid, precision-cutting instruments are needed. Paint-stripping, disaster clean-up, oil-well drilling, and rock-fracturing (via thermal stresses) are other potential applications for these high-powered lasers.

Where it Stands

In research laboratories all over the world, it has taken decades of progress to reach a little more than 5 Watts of power for this laser system. However, over the past year, CU has achieved an order of magnitude increase in lasing power, now standing at over 100 Watts in a subscale system, through advanced discharge technologies, a more complete understanding of the whole laser system, and a larger volume resonator.

Although the ElectricOIL is a “hybrid” electric-gas laser technology, the system continues to evolve and proceed at a “realistic” development pace for a new laser technology, according to the company. It is expected that future interest from contractors will result in partnerships that will advance the technology even further.

More Information

For more information on the ElectricOIL laser, visit http://info.hotims.com/28060-516  . (Source: Joan Zimmermann/ NTTC; MDA TechUpdate, Missile Defense Agency, National Technology Transfer Center Washington Operations).

---

---
