Application of CFD to a Slender-Bodied, Finned Projectile

CFD results agree well with available semi-empirical data.

In an application of computational fluid dynamics (CFD), flow fields about a slender-bodied finned projectile and the resulting aerodynamic forces and moments on the projectile were computed. The size and shape of the projectile (a blunt-nosed, ogivecylinder body, 316.7 mm long, 23.5 mm in diameter, with four tail fins) are representative of a preliminary design of a future air-defense projectile. The computations are exemplary of those needed for predicting aerodynamic performances in order to optimize designs of advanced projectiles, missiles, and rockets in general.

Surface Pressure Contours on the projectile were computed for a speed of Mach 3.5 and an angle of attack of 2°.
The computations were performed by a commercial parallel-processing CFD code that solves the Reynolds-averaged Navier-Stokes equations of flow of a compressible, viscous fluid on computational grids by means of a finite-volume, implicit numerical integration scheme. The numerical scheme includes unifiedgrid, unified-physics, and unified-computing features. This code was used in conjunction with another commercial code that generated the computational grids about the projectile, based on a computer-aided design (CAD) file representing the projectile surfaces.

Turbulence was represented by a cubic k-ε mathematical model - a member of a class of models, commonly used in CFD, that are so named because they include the time-averaged kineticenergy density (k) associated with the local fluctuating (turbulent) component of flow and the time-averaged rate of dissipation (ε) of this turbulent-kinetic- energy density. A pressure/temperature- based inflow/outflow routine was utilized for the inflow boundary condition, while a characteristics-based inflow/outflow routine was used for the far-field boundary condition. A centroidal extrapolation routine was used for the outflow boundary, and an isothermal wall condition was used on the projectile surfaces. The computations were fully three-dimensional: that is, flow fields were not assumed to be symmetrical. All computations were performed under atmospheric conditions of free-stream pressure = 101,325 Pa and temperature = 298 K. Most of the cases were completed by use of 16 processors. The average central-processing- unit time needed to converge on the solution for each case was about 100 hours.

The cases considered included Mach numbers ranging from 1.5 to 5.0 and angles of attack from 0° to 5° (for example, see figure). Steady-state solutions were obtained for these cases. Force and moment data computed from these solutions were found to be acceptably close approximations to available semi-empirical force and moment data.

This work was done by Karen Heavey and Jubaraj Sahu of the Army Research Laboratory. For more information, download the Technical Support Package (free white paper) at www.defensetechbriefs.com/tsp  under the Information Sciences category. ARL-0010

Topics:
Aerodynamics CAD, CAM and CAE Computational fluid dynamics Information Technology Mathematical models Missiles Optimization Simulation and modeling Turbulence Vehicles
This Brief includes a Technical Support Package (TSP).
Document cover
Application of CFD to a Slender-Bodied, Finned Projectile

(reference ARL-0010) is currently available for download from the TSP library.

Don't have an account?

More From SAE Media Group

    Magazine cover
    Defense Tech Briefs Magazine

    This article first appeared in the April, 2007 issue of Defense Tech Briefs Magazine (Vol. 1 No. 2).

    Read more articles from the archives here.

    Overview

    The document is a final report titled "Application of Computational Fluid Dynamics to a Preliminary Extended Area Protection System (EAPS) Projectile," authored by Karen Heavey and Jubaraj Sahu, and published by the U.S. Army Research Laboratory in September 2006. The report spans 30 pages and is designated as ARL-MR-649.

    The primary focus of the report is the application of computational fluid dynamics (CFD) techniques to analyze the aerodynamic performance of a slender-body finned projectile, which is part of the Extended Area Protection System (EAPS). The study aims to compute flow fields and aerodynamic forces and moments acting on the projectile under various conditions.

    The authors employed steady-state numerical methods to conduct simulations across a range of Mach numbers from 1.5 to 5.0, and angles of attack from 0° to 5°. The simulations utilized a cubic k-epsilon turbulence model to achieve full three-dimensional computations. The results obtained from these simulations were compared with available semi-empirical data, demonstrating a good correlation, which validates the effectiveness of the CFD approach in predicting aerodynamic coefficients.

    The report includes an abstract summarizing the key findings, emphasizing the successful application of CFD in understanding the aerodynamic behavior of the projectile. It also discusses the implications of these findings for the design and optimization of projectiles used in military applications, particularly in enhancing their performance and effectiveness in various operational scenarios.

    Additionally, the document contains standard disclaimers, notices regarding the report's classification, and instructions for handling the document. It is noted that the findings should not be construed as an official position of the Department of the Army unless specified by authorized documents.

    Overall, this report contributes valuable insights into the use of computational fluid dynamics in military projectile design, highlighting the importance of advanced simulation techniques in modern defense research and development. The findings are intended to support ongoing efforts to improve the capabilities of military systems, ensuring that they meet the demands of contemporary warfare. The report is approved for public release, making it accessible for further research and application in related fields.
